约翰迪尔零件查询93 - BACKHOE VALVE MOUNTING BRACKET AND COVERS 93 SERIES A, 94, AND 95 SERIES A [A18]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 467 次

Pos.	Part No	Qty	Parts name	Comments
1.	14H812	[14]	Nut	3/8"
2.	12H304	[14]	Lock Washer	3/8"
3.	24H1305	[6]	Washer	13/32" X 13/16" X 0.065"
4.	19H2633	[4]	Cap Screw	HS, SAE 8, 3/8" X 1-1/2"
5.	........	[1]	Box	(SUB FOR AU40601) ( AU41215 NO LONGER AVAILABLE)
5.	........	[1]	Bracket	(USED ON JD544 AND JD644) ( AU44025 USE IF AVAILABLE)
6.	........	[2]	Extension	FOOT REST (FOR USE WITH JD450 TRACTOR ONLY) ( AU13664 NO LONGER AVAILABLE)
7.	19H2676	[2]	Cap Screw	HS, SAE 8, 3/8" X 1"
8.	U40941	[1]	Valve Cover	UPPER
8.	U46741	[1]	Valve Cover	UPPER (USED ON JD544 AND JD644)
9.	U40940	[1]	Valve Cover	LOWER
10.	19H1227	[8]	Cap Screw	HS, SAE 8, 1/4" X 1/2"
10.	19H1227	[AR]	Cap Screw	HS, SAE 8, 1/4" X 1/2" (12 USED WITH JD544 AND JD644)
11.	12H302	[8]	Lock Washer	1/4"
11.	12H302	[AR]	Lock Washer	(12 USED WITH JD544 AND JD644)
12.	24H1287	[8]	Washer	9/32" X 5/8" X 0.065"
12.	24H1287	[12]	Washer	9/32" X 5/8" X 0.065", (12 USED WITH JD544 AND JD644)
13.	........	[1]	Base	L.H. ( U41393 USE IF AVAILABLE)
14.	14H1040	[4]	Nut	1/2", (SUB FOR 14H809)
15.	12H301	[4]	Lock Washer	1/2"
16.	........	[1]	Base	R.H. ( U41392 USE IF AVAILABLE)
17.	19H2898	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-1/4"
18.	19H1648	[8]	Cap Screw	HS, SAE 8, 3/8" X 3/4"
19.	T122182	[1]	Bracket	(SUB FOR U41503)
20.	........	[1]	Deflector	(T33371 USE IF AVAILABLE) (FOR USE WITH JD544 AND JD644 ONLY)
21.	24H1307	[8]	Washer	13/32" X 1" X 1/16"
22.	14H812	[AR]	Nut	3/8", (4 USED WITH JD544 AND JD644)
23.	19H2676	[AR]	Cap Screw	HS, SAE 8, 3/8" X 1" (4 USED WITH JD544 AND JD644)
