约翰迪尔零件查询93 - BACKHOE MAST FRAME AND BOOM PIVOT 93 ( -005700) AND 95 ( -002450) [A20]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 368 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1768	[12]	Cap Screw	HS, SAE 8, 3/4" X 2"
1.	12H236	[12]	Lock Washer	3/4"
2.	........	[2]	Exhaust Cap	( U40453 NO LONGER AVAILABLE)
3.	........	[2]	Dowel Pin	( U40442 NO LONGER AVAILABLE)
4.	........	[2]	Coupling	( U40439 NO LONGER AVAILABLE)
5.	U40443	[2]	Shaft	COLLAR
6.	JD8279	[2]	Bearing Cup
7.	U40519	[AR]	Shim	.508 MM (.020")
7.	U40520	[AR]	Shim	.13 MM (.005")
8.	19H2211	[4]	Cap Screw	1/2" X 5", HS, SAE 8, 1/2" X 5"
8.	12H301	[4]	Lock Washer	1/2"
9.	........	[2]	Stop	(95 ONLY) ( U15805 NO LONGER AVAILABLE)
10.	........	[1]	Mast	( U40521 NO LONGER AVAILABLE)
11.	08H4281	[4]	Cap Screw	1-1/4" X 9-1/2", (93 ONLY)
11.	08H4289	[4]	Cap Screw	1-1/4" X 4-1/2", (95 ONLY)
11.	U16052	[4]	Lock Nut
12.	U16051	[1]	Pin
13.	19H3544	[1]	Cap Screw	HS, SAE 8, 1/2" X 4-1/2"
13.	BP12214	[1]	Lock Nut	(SUB FOR U12622)
14.	U16070	[2]	Bushing	UPPER
15.	JD7797	[4]	Lubrication Fitting	STRAIGHT, 1/4"
16.	........	[1]	Bushing	INCLUDES BUSHINGS ( AU13419 NO LONGER AVAILABLE)
17.	U16068	[2]	Snap Ring
18.	U16071	[1]	Groove Pin
19.	U10618	[2]	Bushing	LOWER
20.	JD7759	[2]	Lubrication Fitting	STRAIGHT, 1/8"
