约翰迪尔零件查询93 - BACKHOE MAST FRAME AND BOOM PIVOT 93 SERIES A, 94, AND 95 SERIES A [A21]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 844 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2211	[4]	Cap Screw	HS, SAE 8, 1/2" X 5"
1.	12H301	[4]	Lock Washer	1/2"
2.	........	[2]	Stop	(95 BACKHOE ONLY) ( U15805 NO LONGER AVAILABLE)
3.	T25879	[4]	Nut	(SUB FOR E12313, THIS APPLICATION)
4.	U41078	[2]	Stud
5.	24H1395	[6]	Washer	25/32" X 1-7/16" X 0.060"
6.	U41089	[2]	Tapered Sleeve
7.	U40831	[1]	Link
8.	U41086	[2]	Bushing
9.	JD7797	[6]	Lubrication Fitting	STRAIGHT, 1/4"
10.	AU40917	[1]	Frame	(USED ON 93 SERIES A BACKHOE, 009000 AND BELOW, AND 95 SERIES A BACKHOE) (SUB FOR U41227)
11.	T67205	[2]	Thrust Washer	(SUB FOR U41077)
12.	19H3210	[4]	Cap Screw	3/4" X 5-1/4", (SUB FOR 19H1892) HS, SAE 8, 3/4" X 5-1/4"
12.	12H236	[4]	Lock Washer	3/4"
13.	U40833	[2]	Coupling
14A.	........	[1]	Pin	( U41080 - NO LONGER AVAILABLE) (SUB T68041)
14B.	AT101652	[1]	Pin Fastener	(SUB FOR U41722 AND T68041)
15.	A3581R	[1]	Spring Locking Pin	(SUB FOR 34H321)
16.	U41088	[2]	Pin Fastener
17.	19H3340	[1]	Cap Screw	HS, SAE 8, 5/8" X 5-1/2"
17.	U14555	[1]	Lock Nut	5/8"
18.	19H3544	[1]	Cap Screw	HS, SAE 8, 1/2" X 4-1/2"
18.	BP12214	[1]	Lock Nut	(SUB FOR U12622) 1/2"
19.	U16051	[1]	Pin
20.	U16070	[2]	Bushing	(A)
21.	AU40588	[1]	Frame	(SUB FOR U41015) (INCLUDES ALL PARTS IDENTIFIED BY (A)
22.	U10618	[2]	Bushing	(1.51" I.D. X 1.99" O.D. X 1.59" LENGTH)
22.	T126936	[2]	Bushing	(A) (SUB FOR T47070)
23.	19H3306	[1]	Cap Screw	HS, SAE 8, 5/8" X 6-1/4"
23.	U14555	[1]	Lock Nut
24.	08H4281	[4]	Cap Screw	1-1/4" X 9-1/2"
24.	08H4289	[4]	Cap Screw	1-1/4" X 4-1/2", (95 ONLY)
24.	U16052	[4]	Lock Nut
25.	U41502	[2]	Bushing
26.	U41099	[1]	Spacer
