约翰迪尔零件查询93 - BACKHOE DIPPERSTICK 93 ( -005700), 93 SERIES A ( -007400), 94 ( -001800), 95 ( -002450),EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 133 次

Pos.	Part No	Qty	Parts name	Comments
1.	U11649	[2]	Washer	BOOM TO DIPPERSTICK
2.	U15846	[1]	Pin
3.	19H3550	[1]	Cap Screw	HS, SAE 8, 1/2" X 4"
3.	BP12214	[1]	Lock Nut	(SUB FOR U12622)
4.	U16017	[2]	Bushing
5.	19H1781	[2]	Cap Screw	HS, SAE 8, 1/2" X 3-1/2"
5.	BP12214	[2]	Lock Nut	(SUB FOR U12622)
6.	U15822	[2]	Pin
7.	U10688	[2]	Bushing
8.	AU13558	[1]	Pin Fastener	CONTROL LINK TO DIPPERSTICK
9.	U11649	[4]	Washer
10.	11H221	[4]	Cotter Pin	3/8" X 2-1/2"
11.	U11121	[2]	Bushing
12.	AU43181	[1]	Pivot	BUSHING TO DIPPERSTICK
13.	U16167	[2]	Link
14.	AU13556	[1]	Pin Fastener	CONTROL LINK TO CYLINDER
15.	T67895	[1]	Link	L.H. (USE ONLY WITH DIPPERSTICK EXTENSION) (SUB FOR U16169) (SUB U42813, THIS APPLICATION)
16.	T67896	[1]	Link	R.H. (USE ONLY WITH DIPPERSTICK EXTENSION) (SUB FOR U16168) (SUB U42813, THIS APPLICATION)
17.	........	[1]	Dipperstick	(SUB FOR AU13494) ( AU41050 NO LONGER AVAILABLE)
18.	JD7759	[2]	Lubrication Fitting	STRAIGHT, 1/8"
