约翰迪尔零件查询93 - BACKHOE SWING CYLINDER 93 ( -005700) AND 95 ( -002450) [F01]EPC John Deere online

广数供应链运营团队, 15 02月, 2025，浏览： 169 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD8279	[2]	Bearing Cup
2.	JD9003	[2]	Bearing Cone
3.	U11034	[1]	Dust Shield	TOP PLATE
3.	U40631	[1]	Shield	TOP PLATE
4.	19H1347	[11]	Cap Screw	3/4" X 1-5/8"
5.	JD7797	[1]	Lubrication Fitting	STRAIGHT, 1/4"
6.	U16334	[4]	Dowel Pin
7.	U40719	[1]	Plate	TOP, (SUB FOR U40445)
8.	U40054	[2]	Pipe Plug	CTSK. HD., 1/8"
9.	15H604	[2]	Pipe Plug	SQ. HD., 1/4"
10.	U40910	[2]	Back-Up Ring	(SUB FOR U10622)
11.	R26543	[2]	O-Ring
12.	U15806	[2]	Seal
13.	U13842	[1]	Vane
14.	U10624	[2]	O-Ring
15.	U15789	[1]	Hydraulic Cylinder Barrel	(FOUR U16334 DOWELS ALSO REQUIRED)
16.	15H638	[2]	Pipe Plug	SQ. HD., 1/8"
17.	U40660	[6]	Seal	(SUB FOR U10619)
18.	T68350	[6]	Screw	5/8" X 2-1/4"
19.	AU13259	[1]	Vane	AND SHAFT ASSEMBLY
20.	19H2710	[6]	Cap Screw	5/8" X 1-3/4"
21.	R69970	[8]	Stud	(SUB FOR U12071)
22.	........	[1]	Plate	(SUB FOR U40446) ( U40720 NO LONGER AVAILABLE)
23.	19H2728	[3]	Cap Screw	3/4" X 3"
24.	19H1526	[2]	Cap Screw	3/4" X 4-1/2"
25.	19H1358	[8]	Cap Screw	7/8" X 1-3/4"
26.	U40632	[1]	Shield	BOTTOM PLATE
27.	AU40435	[1]	Kit	REPAIR SWING CYLINDER, (SUB FOR AU13633)
28.	U41353	[6]	Washer
...	........	[1]	Cylinder	(SUB FOR AU13261) ( AU40485 NO LONGER AVAILABLE)
