| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | ........ | [1] | Plate | BACK (WITH BUSHING) ( AU11847, AT31672 AND AT39025 NO LONGER AVAILABLE) |
| 2. | ........ | [1] | Plate | THRUST BACK, ( U13275 AND T32081 NO LONGER AVAILABLE) |
| 3. | ........ | [1] | Housing | ( AU11977, T32402 AND T40417 NO LONGER AVAILABLE) |
| 4. | U13268 | [2] | Dowel Pin | |
| 5. | ........ | [1] | Gear | ( AU11846 NO LONGER AVAILABLE) (SUB AT31209 IF AVAILABLE) |
| 6. | ........ | [1] | Gear | ( AU11845 NO LONGER AVAILABLE) (SUB AT31210 IF AVAILABLE) |
| 7. | ........ | [1] | Diaphragm | (SUB AT31208) |
| 8. | T32084 | [1] | Gasket | (SUB FOR U13279 AND U41260) |
| 9. | T32083 | [1] | Gasket | (SUB FOR U13280) |
| 10. | T32403 | [1] | Seal | (SUB FOR U13282) |
| 11. | ........ | [2] | Spring | ( U11744 NO LONGER AVAILABLE) |
| 12. | ........ | [2] | Ball | ( U11747 NO LONGER AVAILABLE) |
| 13. | ........ | [1] | Cover | FRONT (WITH BUSHINGS) ( AU11848, AT31671 AND AT39024 NO LONGER AVAILABLE) (SUB AT52687 IF AVAILABLE) |
| 14. | ........ | [4] | Bolt | 3/8" X 3-1/2" ( U13341 AND H29856 NO LONGER AVAILABLE) |
| 15. | AT59652 | [1] | Seal | (SUB FOR U13281) |
| 16. | ........ | [4] | Bolt | 3/8" X 3" ( U13342 NO LONGER AVAILABLE) |
| 17. | 19H2898 | [2] | Cap Screw | 1/2" X 1-1/4" |
| 17. | 12H301 | [2] | Lock Washer | 1/2" |
| 18. | AT31211 | [1] | Kit | PUMP REPAIR, (SUB AT39028) (SUB FOR AU12060 AND AU40817) |
| ... | AT31208 | [1] | Hydraulic Pump | (A) LESS MOUNTING PARTS (COUNTERCLOCKWISE ROTATING FOR 1010, JD350, AND JD450 CRAWLER LOADER) (SUB FOR AU11949) (SUB AT38801) |
| ... | AU11567 | [1] | Hydraulic Pump | LESS MOUNTING PARTS (CLOCKWISE ROTATING FOR 2010 CRAWLER BULLDOZERS) |
