约翰迪尔零件查询310SK TC - BACKHOE, LOADER Front Axle Housing Hubs, Shafts, and Universal Joints with MFWDEPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
869 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AL79902
|
[2] |
Seal
|
|
| 2. |
AT339808
|
[2] |
Tapered Roller Bearing
|
|
| 3. |
T229254
|
[2] |
Shaft
|
|
| 4. |
L100632
|
[4] |
Cross And Bearing Assembly
|
|
| 5. |
T229270
|
[2] |
Yoke
|
|
| 6. |
T153720
|
[2] |
Universal Joint
|
|
| 7. |
AT339629
|
[2] |
Universal Driveshaft
|
|
| 8. |
AL79951
|
[2] |
Seal
|
|
| 9. |
R115119
|
[2] |
Ball Bearing
|
|
| 10. |
T229272
|
[4] |
Screw
|
|
| 11. |
14M7437
|
[4] |
Nut
|
|
| 12. |
19M8011
|
[16] |
Cap Screw
|
|
| 13. |
T229260
|
[2] |
Pin
|
|
| 14. |
T229271
|
[16] |
Bushing
|
|
| 15. |
T229252
|
[1] |
Housing
|
|
| 15. |
T229251
|
[1] |
Housing
|
|
| 16. |
T229285
|
[2] |
Pin
|
|
| 17. |
40M7047
|
[2] |
Snap Ring
|
|
| 18. |
40M5099
|
[2] |
Snap Ring
|
|
| 19. |
L40276
|
[2] |
Snap Ring
|
|
| 20. |
AT339806
|
[2] |
Tapered Roller Bearing
|
|
| 21. |
AL110924
|
[2] |
Seal
|
|
| 22. |
T218484
|
[2] |
Seal
|
|
| 23. |
JD10249
|
[4] |
Tapered Roller Bearing
|
|
| 24. |
T218487
|
[16] |
Stud
|
|
| 25. |
T229273
|
[2] |
Hub
|
|
| 26. |
L40317
|
[2] |
O-Ring
|
|
| 27. |
T281456
|
[16] |
Screw
|
|
