Pos.	Part No	Qty	Parts name	Comments
1.	D10259	[1]	Snap Ring
2.	JD7291	[1]	Bearing Cup
3.	JD7241	[1]	Bearing Cone
4.	T126089	[1]	Drive Shaft	(SUB FOR T100016) (11 AND 16 TEETH, 18 AND 24 SPLINES)
5.	34H266	[1]	Spring Pin	5/32" X 1"
6.	T72837	[2]	Gear
7.	........	[2]	Ring	( T80690 NO LONGER AVAILABLE) (SUB AT168826)
8.	T76149	[2]	Bushing
9.	T118733	[1]	Gear	FOURTH SPEED (36 TEETH) (SUB FOR T100049)
10.	T21442	[AR]	Shim	0.08 MM (.003")
10.	T21443	[AR]	Shim	0.13 MM (.005")
10.	T21444	[AR]	Shim	0.25 MM (.010")
11.	T100017	[1]	Bearing Housing W/O Bearing
12.	19H3239	[3]	Cap Screw	3/8" X 1-1/4"
13.	JD7262	[1]	Bearing Cup
14.	L33269	[1]	Snap Ring	(A) 2.0 MM
14.	L33271	[1]	Snap Ring	(A) 2.1 MM
14.	L33272	[1]	Snap Ring	(A) 2.2 MM
14.	C3937E	[1]	Snap Ring	(A) 1.9 MM
15.	JD8114	[1]	Bearing Cone
16.	U10776	[1]	O-Ring
17.	AT124395	[1]	Seal	(SUB FOR AT14664)
18.	........	[1]	Synchronizer	( AT81349 NO LONGER AVAILABLE) (SUB AT168826)
19.	AT168826	[1]	Synchronizer	(SUB FOR AT74288 AND AT150087)
20.	T78395	[1]	Gear	THIRD SPEED (28 TEETH)
