约翰迪尔零件查询401C - BACKHOE, LOADER LOADER SIDE FRAMES [02C23]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 237 次

Pos.	Part No	Qty	Parts name	Comments
1.	08H4310	[8]	Cap Screw	7/8" X 8-1/2"
2.	U40699	[4]	Strap	REAR
3.	12H245	[8]	Lock Washer	7/8"
4.	14H836	[8]	Nut	7/8"
5.	11H223	[2]	Cotter Pin	3/8" X 2"
6.	24H1228	[2]	Washer	1-17/32" X 2-1/2" X 0.120"
7.	AT41631	[1]	Frame	L.H. (ALSO ORDER (2) L1863N)
8.	U13055	[6]	Clamp
9.	19H3065	[2]	Cap Screw	3/8" X 2"
9.	12H304	[2]	Lock Washer	3/8"
9.	24H1652	[2]	Washer	13/32" X 11/16" X 7/64"
9.	14H812	[2]	Nut	3/8"
10.	19H2994	[4]	Cap Screw	5/8" X 1-1/2"
10.	12H294	[4]	Lock Washer	5/8"
11.	U12948	[2]	Washer
12.	19H2726	[4]	Cap Screw	5/8" X 4"
13.	12H294	[4]	Lock Washer	5/8"
14.	14H1039	[4]	Nut	5/8"
15.	U40559	[2]	Support
16.	AU40734	[1]	Bracket	VALVE MOUNTING
16.	AT53446	[1]	Bracket
17.	19H1895	[3]	Cap Screw	1/2" X 3/4"
17.	24H1625	[3]	Washer	17/32" X 1" X 0.120"
17.	24H1111	[3]	Washer	17/32" X 1-1/16" X 0.090"
18.	19H2458	[2]	Cap Screw	3/8" X 3"
18.	T11234	[2]	Lock Nut
19.	U40701	[2]	Pin
20.	AT41632	[1]	Frame	R.H. (ALSO ORDER (2) L1863N)
21.	19H3445	[2]	Cap Screw	3/8" X 3-3/4"
21.	T11234	[2]	Lock Nut	3/8"
22.	U41455	[2]	Bracket
23.	14H1040	[2]	Nut	1/2", (SUB FOR 14H809)
24.	12H301	[2]	Lock Washer	1/2"
25.	U41534	[6]	Clip
25.	U41534	[2]	Clip
26.	T10671	[6]	Cap Screw
26.	T10671	[2]	Cap Screw
27.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
28.	24H1429	[1]	Washer	29/32" X 1-3/4" X 0.194"
29.	L1863N	[4]	Grommet
