约翰迪尔零件查询401C - BACKHOE, LOADER LOADER CONTROL VALVE LINKAGE [02C24]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
967 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
U43703
|
[1] |
Grip
|
|
| 2. |
U44380
|
[1] |
Lever
|
|
| 3. |
14H821
|
[1] |
Nut
|
|
| 4. |
U10897
|
[1] |
Support
|
|
| 5. |
34H330
|
[4] |
Spring Pin
|
|
| 6. |
U10894
|
[2] |
Link
|
|
| 7. |
U11004
|
[2] |
Pin Fastener
|
|
| 8. |
11M7059
|
[3] |
Cotter Pin
|
|
| 9. |
U10895
|
[1] |
Pivot
|
|
| 10. |
19H1648
|
[2] |
Cap Screw
|
|
| 10. |
12H304
|
[2] |
Lock Washer
|
|
| 11. |
U11000
|
[1] |
Pin Fastener
|
|
| 12. |
U15097
|
[1] |
Pivot
|
|
| 13. |
U11001
|
[1] |
Pin
|
|
| 14. |
U11003
|
[2] |
Pivot
|
|
| 15. |
24H1384
|
[4] |
Washer
|
|
