约翰迪尔零件查询410 - BACKHOE, LOADER FUEL INJECTION PUMP HEAD AND ROTOR (ROOSA-MASTER NO. JDB431AL2410 OR JDB431MD2800) [01E07]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
665 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R30725
|
[2] |
Screw
|
|
| 2. |
R30726
|
[1] |
Dowel Pin
|
|
| 2. |
R49346
|
[1] |
Dowel Pin
|
|
| 3. |
T11926
|
[1] |
Set Screw
|
|
| 4. |
R30727
|
[1] |
Retainer
|
|
| 5. |
AR51706
|
[1] |
Hydraulic Head And Rotor
|
|
| 6. |
T19856
|
[1] |
Valve
|
|
| 6. |
T19857
|
[1] |
Valve
|
|
| 7. |
R30735
|
[1] |
Spring
|
|
| 8. |
T26223
|
[1] |
Stop
|
|
| 9. |
R30737
|
[1] |
Screw
|
|
| 10. |
T11889
|
[1] |
Snap Ring
|
|
| 11. |
T11890
|
[2] |
Retainer
|
|
| 12. |
T20055
|
[8] |
Washer
|
|
| 13. |
R26726
|
[4] |
Hollow Screw
|
|
| 14. |
T11886
|
[2] |
Needle Roller
|
|
| 15. |
R56483
|
[2] |
Shoe
|
|
| 16. |
R30728
|
[2] |
Plunger
|
|
| 16. |
R30729
|
[2] |
Plunger
|
|
| 16. |
R30730
|
[2] |
Plunger
|
|
| 16. |
R30731
|
[2] |
Plunger
|
|
| 17. |
T11887
|
[1] |
Screw
|
|
| 18. |
T11888
|
[1] |
Leaf Spring
|
|
| 19. |
T11891
|
[1] |
O-Ring
|
|
| 20. |
R48501
|
[1] |
Ring
|
|
| ... |
AR34612
|
[1] |
Gasket Kit
|
|
