约翰迪尔零件查询410 - BACKHOE, LOADER FUEL INJECTION PUMP TRANSFER (ROOSA-MASTER NO. JDB431AL2410 OR JDB431MD2800) [01E08]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
216 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T26238
|
[1] |
Sleeve
|
|
| 2. |
R34630
|
[2] |
Spring
|
|
| 3. |
AR73828
|
[1] |
Kit
|
|
| 3. |
AR73829
|
[1] |
Kit
|
|
| 4. |
34H240
|
[1] |
Spring Pin
|
|
| 5. |
R34623
|
[1] |
Plug
|
|
| 6. |
R34622
|
[1] |
Sleeve
|
|
| 7. |
R33259
|
[1] |
O-Ring
|
|
| 8. |
R34625
|
[1] |
Strainer
|
|
| 9. |
R34632
|
[1] |
Washer
|
|
| 10. |
T11899
|
[1] |
O-Ring
|
|
| 11. |
R49209
|
[1] |
Spring
|
|
| 12. |
T11900
|
[1] |
Dowel Pin
|
|
| 13. |
T25142
|
[1] |
Seal
|
|
| 14. |
R34624
|
[1] |
Plate
|
|
| 15. |
R48496
|
[4] |
Clip
|
|
| 16. |
R48497
|
[2] |
Strap
|
|
| 17. |
R48498
|
[4] |
Bolt
|
|
| 18. |
T30607
|
[1] |
Drain Plug
|
|
| 19. |
T26256
|
[1] |
O-Ring
|
|
| 20. |
R34631
|
[1] |
Plate
|
|
| 21. |
T11894
|
[1] |
O-Ring
|
|
| 22. |
RE21439
|
[1] |
Sleeve
|
|
| 23. |
T15715
|
[4] |
Washer
|
|
| ... |
AR34612
|
[1] |
Gasket Kit
|
|
