约翰迪尔零件查询410 - BACKHOE, LOADER FUEL INJECTION PUMP GOVERNOR (ROOSA-MASTER NO. JDB431AL2410 OR JDB431MD2800) [01E09]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
864 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T11932
|
[2] |
Nut
|
|
| 2. |
R34812
|
[2] |
O-Ring
|
|
| 3. |
T11925
|
[1] |
Shaft
|
|
| 4. |
T16602
|
[1] |
Arm
|
|
| 5. |
T25044
|
[1] |
Spring
|
|
| 6. |
T17952
|
[1] |
Washer
|
|
| 7. |
T11924
|
[1] |
Retainer
|
|
| 8. |
T11913
|
[1] |
Spring
|
|
| 9. |
T11914
|
[1] |
Guide
|
|
| 10. |
R74312
|
[1] |
Arm
|
|
| 11. |
T11943
|
[1] |
Washer
|
|
| 12. |
T11923
|
[1] |
Stud
|
|
| 13. |
R30732
|
[1] |
Shim
|
|
| 14. |
AR91548
|
[1] |
Kit
|
|
| 15. |
R58422
|
[1] |
Spring
|
|
| 16. |
R42483
|
[1] |
Ring
|
|
| 17. |
AR63213
|
[1] |
Hub
|
|
| 18. |
AR63212
|
[1] |
Retainer
|
|
| 19. |
AR51989
|
[1] |
Retainer
|
|
| 20. |
T11931
|
[1] |
Ring
|
|
| 21. |
T11910
|
[6] |
Weight
|
|
| 22. |
T11909
|
[1] |
Washer
|
|
| 23. |
R74472
|
[1] |
Sleeve
|
|
| ... |
AR34612
|
[1] |
Gasket Kit
|
|
