约翰迪尔零件查询410 - BACKHOE, LOADER FRONT SUPPORT [01G06]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 448 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2358	[2]	Cap Screw	9/16" X 2-1/4"
2.	12H317	[2]	Lock Washer	9/16"
3.	T26929	[2]	Bushing
4.	AT51312	[1]	Support	FRONT, (MARKED T66816) (INCLUDES BAFFLES, HOLLOW DOWELS, PIVOT PIN, BUSHINGS AND GREASE FITTINGS) (SUB FOR AT32704, MARKED T33511) (SUB AT63367, MARKED T72536)
4.	AT63367	[1]	Support	FRONT, (MARKED T72536) (INCLUDES BAFFLES, HOLLOW DOWELS, PIVOT PIN, BUSHINGS AND GREASE FITTINGS)
5.	T36498	[1]	Barrier
6.	34H340	[4]	Spring Pin	5/16" X 13/16"
7.	12H294	[4]	Lock Washer	5/8"
8.	19H3107	[4]	Cap Screw	5/8" X 2-3/4"
9.	T21540	[2]	Pad
10.	T23118	[1]	Bushing
11.	JD7799	[1]	Lubrication Fitting	1/8"
12.	T22864	[1]	Cover
13.	19H2021	[2]	Cap Screw	3/8" X 5/8"
14.	12H304	[2]	Lock Washer	3/8"
15.	19H2728	[2]	Cap Screw	3/4" X 3"
16.	12H236	[2]	Lock Washer	3/4"
17.	R54124	[1]	Washer	6.0 MM (.235") (SUB FOR T40983)
17.	T36034	[1]	Washer	6.2 MM (.245")
17.	T36035	[1]	Washer	6.5 MM (.255")
17.	T36036	[1]	Washer	6.7 MM (.265")
17.	T36037	[1]	Washer	7.0 MM (.275")
17.	T36038	[1]	Washer	7.2 MM (.285")
17.	T37417	[1]	Washer	7.5 MM (.295")
18.	T34441	[1]	Pin Fastener	(SUB T53267 AND JD7781)
18.	T53267	[1]	Pin Fastener	REAR
19.	JD7788	[1]	Lubrication Fitting	1/4"
19.	JD7781	[1]	Lubrication Fitting	1/8" (SUB FOR JD7763, THIS APPLICATION)
20.	C15599	[AR]	Washer
