约翰迪尔零件查询410 - BACKHOE, LOADER HYDRAULIC OIL LINES (TO PUMP, CLUTCH CONTROL VALVE, FILTER RELIEF VALVE AND RETURN) [01I01]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 901 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT33918	[1]	Oil Line
2.	AT33917	[1]	Elbow Fitting
3.	R26287	[1]	O-Ring
4A.	AT32335	[1]	Elbow Fitting	(SUB FOR AR26746)
4B.	T21806	[1]	Drain Plug
5.	19H1914	[2]	Cap Screw	1/4" X 1"
6.	AT25345	[1]	Line	(HYDRAULIC PUMP TO BRAKE VALVE HOUSING)
6.	AT25345	[1]	Line	(HYDRAULIC PUMP TO CLUTCH HOUSING COVER)
6.	AT63378	[1]	Line
7.	R44302	[7]	Tie Band
8.	AR21839	[4]	Clamp	(SUB FOR H2742B, THIS APPLICATION)
9.	........	[1]	Hose	57 MM LONG (3/4" X 2-1/4") (MAKE FROM T61939) (SUB FOR T35690)
10.	14H785	[2]	Nut	5/16"
11.	T36048	[2]	Bracket
12.	T36200	[2]	Clamp
13.	T34888	[2]	Clamp
14.	12H303	[2]	Lock Washer	5/16"
15.	19H1849	[2]	Cap Screw	5/16" X 1-1/4"
16.	AT33913	[1]	Oil Line	COOLER TO CLUTCH CONTROL VALVE
17.	U13639	[1]	O-Ring
18.	AT33911	[1]	Elbow Fitting	OIL RETURN LINE TO HYDRAULIC PUMP
19.	AT33919	[1]	Oil Line
20.	........	[1]	Hose	76 MM (1" X 3") (MAKE FROM U11186) (SUB FOR T35691 AND T37798)
21.	AT33921	[1]	Oil Line
22.	AT33923	[1]	Adapter Fitting
23.	19H2676	[1]	Cap Screw	3/8" X 1", LINES TO CLUTCH CONTROL VALVE
24.	R43696	[1]	Washer	(SUB FOR A4231R)
25.	R1662R	[2]	Washer
26.	14H786	[2]	Nut	1/4"
27.	24H1287	[2]	Washer	9/32" X 5/8" X 0.065"
