| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1A. | AR21839 | [4] | Clamp | (SUB FOR H2742B, THIS APPLICATION) |
| 1B. | AR21839 | [2] | Clamp | (SUB FOR H2742B, THIS APPLICATION) |
| 2. | ........ | [1] | Hose | 57 MM LONG (3/4" X 2-1/4") (MAKE FROM T61939) (SUB FOR T35690) |
| 3A. | T34881 | [1] | Oil Line | (SUB T61939) (SEE KEY 3B) |
| 3A. | T34881 | [1] | Oil Line | (SUB R58921) (SEE KEY 3B) |
| 3B. | ........ | [1] | Hose | 622 MM LONG (3/4" X 24-1/2") (MAKE FROM T61939) (SUB FOR T34881) |
| 3B. | R58921 | [1] | Hose | 565 MM (3/4" X 22-1/2") (SUB FOR T34881 AND T61939, THIS APPLICATION) |
| 4. | ........ | [1] | Hose | 127 MM LONG (3/4" X 5") (MAKE FROM T61939) (SUB FOR T21371) |
| 4. | ........ | [1] | Hose | 57 MM LONG (3/4" X 2-1/4") (MAKE FROM T61939) (SUB FOR T35690) |
