约翰迪尔零件查询410 - BACKHOE, LOADER FRONT WHEEL ASSEMBLY [01I05]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 972 次

Pos.	Part No	Qty	Parts name	Comments
1.	AR27806	[1]	Seal
2.	R28574	[1]	Seal
3.	JD9052	[1]	Bearing Cone	INNER
3.	JD8131	[1]	Bearing Cone	INNER
4.	JD7426	[1]	Bearing Cup	INNER
4.	JD7439	[1]	Bearing Cup	INNER
5.	T33604	[1]	Hub
5.	T41358	[1]	Hub	(SUB R63556, DT2127W AND 22H841)
5.	R63556	[1]	Hub	(8 HOLES)
6.	JD8251	[1]	Bearing Cup	OUTER
6.	JD7266	[1]	Tapered Roller Bearing	OUTER
7.	JD8929	[1]	Bearing Cone	OUTER
7.	JD10190	[1]	Bearing Cone	OUTER, (SUB FOR JD8981)
8.	JD3044	[1]	Rim	(9.00 X 16" TIRE)
8.	JD3045	[1]	Wheel	(7.50 X 16" TIRE)
8.	AT310291	[1]	Wheel	(SUB FOR JD3216) (11.00 X 16" TIRE)
9.	JD27	[8]	Screw
10.	11M7030	[1]	Cotter Pin	5 X 40 MM
11.	A5146R	[1]	Washer
11.	R28575	[1]	Washer
12.	14H920	[1]	Nut	1", (USE WITH AT46780)
12.	14M7519	[1]	Nut	M24, (USE WITH AT76138)
13.	A1556R	[1]	Gasket
14A.	A1555R	[1]	Cap
14B.	DT2127W	[1]	Cap
15A.	15H638	[1]	Pipe Plug	1/8"
15B.	22H841	[1]	Set Screw	1/4" X 1/4"
16.	24H1136	[3]	Washer	11/32" X 11/16" X 0.065"
17.	19H2915	[3]	Cap Screw	5/16" X 1-1/4"
18.	AT25226	[1]	Tire Valve Stem	USE WITH CALCIUM CHLORIDE, (SUB FOR AT38142)
