约翰迪尔零件查询410 - BACKHOE, LOADER CAB HEATER AND HOSES (SERIAL NO. -388072) [02B24]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询410 - BACKHOE, LOADER CAB HEATER AND HOSES (SERIAL NO. -388072) [02B24]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 474 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1919	[4]	Cap Screw	1/4" X 5/8"
2.	12H302	[4]	Lock Washer	1/4"
3.	T37023	[1]	Bracket
4.	14H812	[4]	Nut	3/8"
5.	AR21837	[4]	Clamp	(SUB FOR AR21839, THIS APPLICATION)
6.	H23197	[2]	Grommet
7.	........	[1]	Hose	(SUB FOR T37025) (MAKE FROM T60811 BULK MATERIAL CUT TO LENGTH) (1 277MM(50"LONG)
8.	R41985	[1]	Fitting	(SUB FOR H23196, THIS APPLICATION)
9.	T24432	[1]	Clamp	HOSE TO CYLINDER BLOCK
9.	........	[1]	Clip	( R29131 NO LONGER AVAILABLE)
10.	12H301	[1]	Lock Washer	1/2"
10.	12H317	[1]	Lock Washer	9/16"
11.	19H2472	[1]	Cap Screw	1/2" X 1"
11.	19H3649	[1]	Cap Screw	9/16" X 1"
12.	T37027	[1]	Fitting
13.	AT35831	[1]	Drain Valve
14.	........	[1]	Hose	(SUB FOR T37026) (MAKE FROM T60811 BULK MATERIAL CUT TO LENGTH) (1 867MM(73"LONG)
15.	AT35830	[1]	Wiring Lead
15.	AT28061	[1]	Fuse	5 AMP
16.	T37024	[1]	Bracket
17.	AU42189	[1]	Switch
18.	AA4927R	[1]	Bulb	12-VOLT
19.	24H1305	[4]	Washer	13/32" X 13/16" X 0.065"
20.	19H2284	[4]	Cap Screw	3/8" X 7/8"
21.	AT140290	[1]	Heater	(SUB FOR AT27086 OR AT114647)
21.	AT140290	[1]	Heater	(SUB FOR AT63076)
22.	T54089	[1]	Guard
23.	H77698	[2]	Tie Band	(SUB FOR T44946)
...	AT73383	[1]	Heater	(INCLUDES ALL PART NUMBERS ABOVE AND T37041 ELBOW) (SUB FOR AT37345)
