约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE BUCKET CYLINDER (SERIAL NO. 335231- ) [02I09]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 447 次

Pos.	Part No	Qty	Parts name	Comments
1.	22H1077	[1]	Set Screw	1/4" X 5/16"
2.	L2235CU	[1]	Lock Nut
3.	U17217	[1]	Wear Ring	(A)
4.	T36039	[1]	Piston
5.	T38193	[1]	Packing	(A) (SUB FOR T35851)
6.	R29463	[1]	O-Ring	(A)
7.	U17219	[1]	Piston	INNER, (SUB R78222 AND RE18758, THIS APPLICATION)
8.	W11229	[1]	Ring
9.	R76790	[1]	Packing	(A) (SUB FOR T35851)
10.	JD7759	[1]	Lubrication Fitting	1/8", STRAIGHT
11.	T25898	[1]	Bushing
12.	AT32777	[1]	Hydraulic Cylinder Rod
13.	U11022	[1]	Seal	(A)
14.	R80919	[1]	Guide	(SUB FOR T57006)
15.	U41822	[1]	Wear Ring	(A)
16.	R79101	[1]	Back-Up Ring	(A) (SUB FOR T42045, THIS APPLICATION)
17.	F1430R	[1]	O-Ring	(A)
18.	U10666	[2]	Bushing
19.	AR90637	[1]	Hydraulic Cylinder Barrel
20.	JD7763	[1]	Lubrication Fitting	1/4"
21.	........	[1]	Hydraulic Cylinder	RE12720 NO LONGER AVAILABLE, (SUB FOR AR90635)
22.	R26906	[1]	O-Ring	(A)
23.	R27270	[1]	Fitting
24.	AT63290	[1]	Line
25.	AC15595	[1]	Clamp	(SUB FOR AT63291)
26.	T66715	[1]	Spacer
...	RE18757	[1]	Hydraulic Cylinder Kit	(SUB FOR AT36833, AR99789 AND AR105354)
