约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE SWING CYLINDER (SERIAL NO. 303203- ) [02I12]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 269 次

Pos.	Part No	Qty	Parts name	Comments
1.	R81342	[1]	Hydraulic Cylinder Cap	(SUB FOR U43461)
2.	L2309CU	[1]	Back-Up Ring	(A)
3.	L2301CU	[1]	O-Ring	(A)
4.	22H842	[2]	Set Screw	1/4" X 5/16"
5.	U43454	[2]	Bushing
6.	AT56435	[1]	Hydraulic Cylinder Barrel	(SUB AR104410)
6.	AR104410	[1]	Hydraulic Cylinder Barrel
7.	T162396	[2]	Lubrication Fitting	(SUB FOR JD7798) 1/8"
8.	L2235CU	[1]	Lock Nut
9.	U44491	[1]	Piston Ring
10.	T37360	[1]	Piston
11.	U17337	[1]	Wear Ring	(A)
12.	R29463	[1]	O-Ring	(A)
13.	T37381	[1]	Packing	(A) (SUB FOR R72830)
14.	U17347	[1]	Piston	(SUB R77809 AND RE18741, THIS APPLICATION)
15.	A5598R	[1]	O-Ring	(A)
16.	R79122	[1]	Back-Up Ring	(A) (SUB FOR T42032, THIS APPLICATION)
17.	N10193	[1]	Snap Ring
18.	R76801	[1]	Packing	(A) (SUB FOR T35850)
19.	U41578	[1]	Wear Ring	(A)
20.	T57011	[1]	Guide	(SUB FOR T57011)
21.	L2029CU	[1]	Seal	(A)
22.	JD7797	[1]	Lubrication Fitting	1/4"
23.	T33708	[1]	Bushing
24.	AT56434	[1]	Hydraulic Cylinder Rod
...	AT56433	[1]	Hydraulic Cylinder	(SUB AR104408)
...	AR104408	[1]	Hydraulic Cylinder
...	AR105387	[1]	Hydraulic Cylinder Kit	(SUB FOR AT52710 AND AR96530)
