约翰迪尔零件查询410B - BACKHOE, LOADER HYDRAULIC PUMP TO PRIORITY VALVE OIL LINE (SERIAL NO. 718116- ) [02H21]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
742 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R29936
|
[1] |
O-Ring
|
|
| 2. |
38H1164
|
[1] |
Adapter Fitting
|
|
| 3. |
AT100978
|
[1] |
Hydraulic Hose - Fabricate
|
|
| 4. |
19H2994
|
[1] |
Cap Screw
|
|
| 5. |
AT75557
|
[1] |
Bracket
|
|
| 6. |
AT75558
|
[1] |
Bracket
|
|
| 7. |
T68526
|
[1] |
Bar
|
|
| 8. |
19H2633
|
[2] |
Cap Screw
|
|
| 9. |
38H1179
|
[1] |
Adapter Fitting
|
|
| 10. |
U12547
|
[1] |
O-Ring
|
|
| 11. |
AT81668
|
[1] |
Oil Line
|
|
| 12. |
24M7233
|
[2] |
Washer
|
|
| 13. |
T77025
|
[2] |
Clamp
|
|
| 14. |
19M7753
|
[4] |
Cap Screw
|
|
| 15. |
T21242
|
[2] |
Washer
|
|
| 16. |
T28949
|
[2] |
Clamp
|
|
| 17. |
U41353
|
[1] |
Washer
|
|
| 18. |
24H1367
|
[1] |
Washer
|
|
| 19. |
T76938
|
[3] |
O-Ring
|
|
