| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7361 | [2] | Cap Screw | M12 X 50 |
| 2. | 24M7240 | [2] | Washer | 13 X 25 X 3 MM |
| 3. | 14M7275 | [4] | Nut | M12 |
| 4. | T135590 | [2] | Bar | |
| 5. | AT165548 | [1] | Frame | (SUB FOR AT146306) |
| 6. | T149398 | [1] | Grille | (SUB FOR T135582) |
| 7. | 19M7402 | [6] | Cap Screw | M10 X 25 |
| 8. | 24M7296 | [6] | Washer | 10.500 X 30 X 2.500 MM STEEL |
| 9. | 14M7276 | [2] | Nut | M16 |
| 10. | 24M7241 | [4] | Washer | 17 X 34 X 4 MM |
| 11. | 19M8295 | [2] | Cap Screw | M16 X 55 (SUB FOR 19M7480) |
| 12. | 19M7363 | [2] | Cap Screw | M12 X 60 |
| 13. | T29342 | [2] | Washer | |
| 14. | T145936 | [6] | Washer | 9.910 X 32 X 1.570 MM (0.390" X 1.260" X 1/16") NYLON |
