| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T166815 | [1] | Pin | |
| 2. | T166235 | [1] | Bracket | |
| 3. | F2863R | [1] | Snap Ring | |
| 4. | B177R | [2] | Bushing | |
| 5. | 14M7273 | [2] | Nut | M8 |
| 6. | 19M7164 | [2] | Cap Screw | M8 X 50 |
| 7. | AT185087 | [1] | Pedal | (RH) |
| 8. | 24H1381 | [2] | Washer | 23/32" X 1-1/4" X 0.060" |
| 9. | AT185086 | [1] | Pedal | (LH) |
| 10. | R50034 | [1] | Leaf Spring | |
| 11. | R50879 | [1] | Arm | |
| 12. | 34H312 | [1] | Spring Pin | 1/4" X 1" |
