卡特零件查询（740） 141-6884: TANK & MTG GP-HYDRAULIC
广数供应链运营团队, 16 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6C-9149 | [6] | WASHER(22X50X10-MM THK) | |
| 2. | 9W-6582 | [3] | SLEEVE | |
| 3. | 9W-6584 | [3] | WASHER(20.5X114X10-MM THK) | |
| 4. | 9W-9920 | [3] | MOUNTING AS-VIBRATION ISOLATOR | |
| 5. | 162-5242Y | [1] | TANK GP-HYDRAULIC(HOIST) | |
| 6. | 8T-4170CM | [3] | BOLT(M20X2.5X150-MM) | |
| 7. | 205-3984 | [3] | WASHER-SPECIAL | |
| 8. | 8T-4131M | [3] | NUT(M20X2.5-THD) | |
| 9. | 092-2267B | [4] | SHIM(2-MM THK) | |
| | B | | USE AS REQUIRED |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
