卡特零件查询（AP-1055D） 249-9223: STARTING AID GP
广数供应链运营团队, 16 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 398-0940Y | [1] | SWITCH GP-MAGNETIC(24-VOLT)(AIR INLET HEATER RELAY) | |
| 2. | 229-8851 | [1] | CABLE AS | |
| | 125-7876E | | TUBE-HEAT SHRINK(17.78-MM DIA)(4-CM) | |
| | 308-8161 | [1] | COVER-TERMINAL | |
| | 316-5240 | [1] | COVER-TERMINAL | |
| 3. | 283-1224 | [1] | BRACKET AS | |
| 4. | 208-9277M | [2] | BOLT-FLANGE HEAD(M6X1X20-MM) | |
| 5. | 208-9282M | [4] | BOLT(M8X1.25X25-MM) | |
| 6. | 208-9283M | [2] | BOLT-FLANGE HEAD(M8X1.25X30-MM) | |
| 7. | 6V-5192M | [1] | BOLT-SOCKET HEAD(M8X1.25X30-MM) | |
| 8. | 9M-1974 | [1] | WASHER-HARD(8.8X16X2-MM THK) | |
| 9. | 3S-2093 | [1] | STRAP-CABLE | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
