| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 177-2215 | [1] | STRAP-DUAL CLAMP | |
| 2. | 214-7859I | [1] | HOSE AS | |
| 3. | 233-8467I | [1] | HOSE AS | |
| 4. | 148-8353 | [1] | ELBOW AS | |
| 3J-1907 | [1] | SEAL-O-RING | ||
| 6V-8397 | [1] | SEAL-O-RING | ||
| 6V-9001 | [1] | ELBOW | ||
| 5. | 148-8417 | [1] | REDUCER AS | |
| 6V-8397 | [1] | SEAL-O-RING | ||
| 6V-8941 | [1] | REDUCER | ||
| 6. | 6D-4246 | [4] | CLIP(LOOP) | |
| 7. | 9X-6580 | [1] | NUT(1-3/16-12-THD) | |
| 8. | 8T-4133M | [1] | NUT(M10X1.5-THD) | |
| I | REFER TO HYDRAULIC INFORMATION SYSTEM | |||
| M | METRIC PART | |||
