卡特零件查询（AP-1055F） 392-4701: LINES GP-BRAKE & SHIFT
广数供应链运营团队, 16 02月, 2025，浏览：
586 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 423-8497I | [1] | HOSE AS | |
| 2. | 423-8500I | [1] | HOSE AS | |
| 3. | 423-8501I | [1] | HOSE AS | |
| 4. | 423-8502I | [1] | HOSE AS | |
| 5. | 423-8503I | [1] | HOSE AS | |
| 6. | 433-3488I | [1] | HOSE AS | |
| 7. | 433-3489I | [1] | HOSE AS | |
| 8. | 433-3490I | [1] | HOSE AS | |
| 9. | 149-5452 | [2] | UNION AS(STRAIGHT) | |
| | | | (EACH INCLUDES) |
| | 6V-8397 | [2] | SEAL-O-RING | |
| | 6V-8994 | [1] | UNION(STRAIGHT) | |
| 10. | 177-2215 | [2] | STRAP-DUAL CLAMP | |
| 11. | 200-6345 | [2] | SADDLE-MOUNTING(DUAL SWIVEL) | |
| 12. | 204-2281 | [4] | STRAP-CABLE | |
| 13. | 327-0325 | [4] | STRAP-CABLE | |
| 14. | 6V-9168 | [2] | NUT(11/16-16-THD) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
