卡特零件查询（AP-655C） 219-6313: GENERATOR GP-HYDRAULIC
广数供应链运营团队, 16 02月, 2025，浏览：
923 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5P-7807J | [1] | BALL BEARING | |
| 2. | 6K-8162J | [1] | RING-RETAINING | |
| 3. | 177-4444J | [1] | FAN | |
| 4. | 177-4445 | [2] | SUPPORT | |
| 5. | 177-4446H | [6] | BRUSH | |
| 6. | 177-4447H | [2] | RETAINER | |
| 7. | 177-4448 | [2] | KIT-RECTIFIER(HYDRAULIC GENERATOR) | |
| 8. | 177-4450 | [3] | SHOCK ABSORBER | |
| 9. | 178-7393 | [1] | PLATE-MOUNTING | |
| 10. | 227-3030J | [1] | RING | |
| 11. | 227-3031Y | [1] | MOTOR GP-GEAR(HYDRAULIC GENERATOR) | |
| 12. | HZ | [2] | GROMMET |
| 13. | HZ | [1] | ENDBELL AS |
| 14. | JZ | [1] | ROTOR |
| 15. | Z | [1] | HOUSING |
| 16. | Z | [8] | BOLT |
| 17. | Z | [2] | WASHER |
| 18. | Z | [2] | NUT |
| 19. | Z | [8] | SCREW |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 178-7394H | [1] | KIT-PLATE(HYDRAULIC GENERATOR) | |
| | 227-3034J | [1] | KIT-ROTOR(HYDRAULIC GENERATOR) | |
| | H | | INCLUDES PARTS MARKED H |
| | J | | INCLUDES PARTS MARKED J |
| | Y | | SEPARATE ILLUSTRATION |
| | Z | | NOT SERVICED SEPARATELY |
