卡特零件查询（AP-655C） 273-9163: HARNESS AS-CHASSIS
广数供应链运营团队, 16 02月, 2025，浏览：
257 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 7R-7029 | [1] | CONNECTOR-RECEPTACLE(6-PIN) | |
| | 195-5219 | [1] | CONNECTOR(3-PIN) | |
| | 9X-0141 | [1] | PLUG AS-CONNECTOR(40-PIN) | |
| | 3E-8557M | [1] | BOLT(M5X0.8X39.37-MM) | |
| | 3E-4367 | [1] | RING-RETAINING | |
| | 9X-3490 | [2] | SEAL-CONNECTOR(40-PIN) | |
| | 155-2260 | [1] | KIT-CONNECTING PLUG(3-PIN) | |
| | 155-2270 | [4] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2271 | [1] | KIT-CONNECTING PLUG(4-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 8T-8737 | [18] | PLUG-SEAL | |
| | 132-6773 | [1] | CONNECTOR-RECEPTACLE(11-PIN) | |
| | 8T-8730 | [37] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 5P-2321 | [4] | TERMINAL-FORK(14-GA TO 16-GA, NO. 6 SCREW) | |
| | 2L-8054 | [1] | TERMINAL-RING(6-GA, 1/2-IN SCREW) | |
| | | | -OR- |
| | 2L-8061 | [1] | TERMINAL-RING(8-GA, 1/2-IN SCREW) | |
| | 2L-8064 | [3] | TERMINAL-RING(10-GA TO 12-GA, NO. 6 SCREW) | |
| | 2L-8071 | [3] | TERMINAL-RING(10-GA TO 12-GA, 1/2-IN SCREW) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(10-CM) | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
