卡特零件查询（AP-655C） 219-2455: PUMP GP-FUEL TRANSFER
广数供应链运营团队, 16 02月, 2025，浏览：
474 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5C-1777 | [5] | NUT | |
| 2. | 6I-0217M | [1] | BOLT(M8X1.25X20-MM) | |
| 3. | 6I-0254M | [4] | BOLT(M8X1.25X30-MM) | |
| 4. | 6I-1090M | [1] | BOLT(M8X1.25X40-MM) | |
| 5. | 033-7849 | [1] | PLUG | |
| 6. | 067-6269 | [4] | FERRULE | |
| 7. | 100-4830M | [3] | BOLT(M10X1.5X20-MM) | |
| 8. | 101-3906 | [1] | BOLT | |
| 9. | 101-3907 | [2] | WASHER | |
| 10. | 101-7178M | [1] | BOLT(M10X1.5X55-MM) | |
| 11. | 102-9988 | [1] | SPACER | |
| 12. | 127-8162 | [1] | CLIP | |
| 13. | 162-2000 | [1] | WASHER | |
| 14. | 216-9043 | [1] | PUMP AS-FUEL TRANSFER | |
| 14A. | 231-4457 | [1] | GASKET | |
| 15. | 216-9053 | [1] | CONNECTOR | |
| 16. | 216-9086 | [1] | SPACER(10.5X20X32-MM THK) | |
| 17. | 216-9092 | [1] | CONNECTOR-SPECIAL(BANJO) | |
| 18. | 216-9752 | [4] | WASHER | |
| 19. | 217-0721 | [1] | BOLT-SPECIAL(BANJO) | |
| 20. | 219-2443 | [1] | TUBE AS | |
| 20A. | 102-9986 | [1] | CLIP | |
| 20B. | 067-6268 | [1] | NUT-FUEL LINE | |
| 20C. | 067-6269 | [1] | FERRULE | |
| 21. | 219-2450 | [1] | BRACKET | |
| 22. | 219-2451 | [1] | CONNECTOR-SPECIAL(BANJO) | |
| 23. | 219-2452 | [1] | BALL | |
| 24. | 219-2453 | [1] | TUBE AS | |
| 24A. | 149-6117 | [1] | CLIP | |
| 25. | 223-5418 | [1] | TUBE AS | |
| 25A. | 067-6268 | [2] | NUT-FUEL LINE | |
| 25B. | 067-6269 | [2] | FERRULE | |
| 25C. | 102-9986 | [1] | CLIP | |
| 25D. | 102-9987 | [1] | CLIP | |
| | M | | METRIC PART |
