卡特零件查询（AP-655D） 304-9102: WIRING GP-HEATER
广数供应链运营团队, 17 02月, 2025，浏览：
542 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 116-0118 | [1] | CLIP | |
| 2. | 8T-4224 | [4] | WASHER-HARD(8.8X16X2-MM THK) | |
| 3. | 289-5816Y | [1] | BOX GP-JUNCTION | |
| 4. | 8T-0642M | [2] | BOLT(M8X1.25X14-MM) | |
| 5. | 309-2703 | [1] | HARNESS AS-WIRING(750-MM EXTENSION, RH) | |
| | 232-0897E | | CONDUIT-FLEXIBLE(16.2-MM ID)(139-CM) | |
| | 9X-3401 | [6] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | | | -OR- |
| | 126-1767 | [6] | PIN-CONNECTOR(14-GA TO 16-GA) | |
| | 129-7163 | [4] | PLUG AS-CONNECTOR(1-PIN) | |
| | 155-2274 | [1] | KIT-CONNECTING PLUG(6-PIN) | |
| | | | (INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) |
| | 9G-3695 | [6] | PLUG-SEAL | |
| | 102-8805 | [2] | KIT-RECEPTACLE(6-PIN) | |
| | | | (EACH INCLUDES RECEPTACLE AS & WEDGE) |
| | 114-8843E | | SLEEVE-PLASTIC(160-CM) | |
| | 8N-1541 | [4] | SOCKET-CONNECTOR(12-GA TO 14-GA) | |
| | 194-5226 | [6] | WIRE AS(16-GA) | |
| | | | -OR- |
| | 194-5227 | [6] | WIRE AS(14-GA) | |
| | 2L-8065 | [1] | TERMINAL-RING(10-GA TO 12-GA, NO. 8 SCREW) | |
| | 2L-8069 | [3] | TERMINAL-RING(2-GA TO 10-GA, 3/8-IN SCREW) | |
| | 8T-2225E | | TUBE-HEAT SHRINK(25.4-MM DIA)(30-CM) | |
| 6. | 314-8916 | [1] | CABLE AS-POWER | |
| | 5P-5624D | | WIRE(14-GA, BLACK)(0.3-M) | |
| | 8T-2225E | | TUBE-HEAT SHRINK(25.4-MM DIA)(10-CM) | |
| | 8N-1541 | [2] | SOCKET-CONNECTOR(12-GA TO 14-GA) | |
| | 114-8843E | | SLEEVE-PLASTIC(40-CM) | |
| | 129-7163 | [2] | PLUG AS-CONNECTOR(1-PIN) | |
| 7. | 130-5300 | [6] | CLIP | |
| 8. | 8T-0328 | [4] | WASHER-HARD(5.5X10X1-MM THK) | |
| 9. | 5C-2874M | [2] | NUT(M5X0.8-THD) | |
| 10. | 7I-2273M | [2] | BOLT(M5X0.8X16-MM) | |
| 11. | 7F-6998 | [2] | LOCKWASHER | |
| 12. | 101-3917 | [3] | WASHER(10.5X21X2-MM THK) | |
| 13. | 8T-4133M | [1] | NUT(M10X1.5-THD) | |
| 14. | 6V-8212M | [1] | BOLT(M10X1.5X16-MM) | |
| | D | | ORDER BY THE METER |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
